Description
SPRO 5MP 4in1 Fixed Lens Turret with COLOUR NIGHT
| Specifications: | |
| Model Number | DHD50/28LW/20M-4-M |
| Image Sensor | 1/2.7 inch CMOS |
| Effective Pixels | 2592 (H) × 1944 (V), 5MP |
| Electronic Shutter Speed | 1/25~1/100000s |
| S/N Ratio | More than 65dB |
| Min. Illumination | 0.02Lux/F1.2, 0Lux White Light on |
| Fill Light (White Light) Distance | Distance up to 20m |
| Fill Light On/Off Control | Auto/ Manual |
| Fill Light Number | 1 |
| Lens | |
| Lens Type | Fixed lens |
| Mount Type | M12 |
| Focal Length | 2.8mm |
| Max Aperture | F1.2 |
| Angle of View | H: 129°, V: 98° |
| Iris Type | Fixed iris |
| Close Focus Distance | 1.6 m |
| DORI Distance | Detect: 63.0 m Observe: 25.0 m Recognize: 13.0 m Identify: 6.0 m |
| Pan / Tilt / Rotation | |
| Pan/Tilt/Rotation | Pan:0˚~360˚ / Tilt: 0° ~ 180° / Rotation: 0° ~ 360° |
| Video | |
| Video Frame Rate | CVI: PAL: 5M@20fps, 4M@25fps, 1080P@25fps; AHD: PAL: 5M@20fps, 4M@25fps; TVI: PAL: 5M@20fps, 4M@25fps; CVBS: PAL: 960H |
| Resolution | 5M (2592 × 1944); 4M (2560 × 1440); 1080P (1920 × 1080); 960H (704 × 576/704 × 480) |
| BLC Mode | BLC / HLC / DWDR |
| WDR | DWDR |
| White Balance | Auto / Manual |
| Gain Control | Auto / Manual |
| Noise Reduction | 2D NR |
| Smart Light | Yes |
| Mirror | Off/On |
| Privacy Masking | Off/On (8 area, rectangle) |
| Interface | |
| Audio Interface | Built-in mic |
| Port | |
| Video Port | Video output choices of CVI/TVI/AHD/CVBS by one BNC port |
| General | |
| Power Supply | DC12V±30% |
| Power Consumption | Max 3.0W (12V DC, white light on) |
| Operating Conditions | -40°C ~ +60°C / Less than 95% RH |
| Strorage Conditions | -40°C ~ +60°C / Less than 95% RH |
| Protection Grade | IP67 |
| Casing | Metal + Plastic |
| Dimensions | φ85.5 mm × 109 mm |
| Net Weight | 0.24kg |
| Gross Weight | 0.37kg |
